Will Apache Hama Have Its Day in HPC?

Apache Hama is a distributed framework based on a bulk synchronous parallel computing approach that is designed to efficiently tackle select problems that Hadoop chokes on, including graph and matrix algorithms.

Although its Apache release was relatively recent (last March), Hama has been around since 2010 after capitalizing on some of the early successes of the Pregel graph computing approach developed by Google. At the high level, Hama sits on top of Hadoop and provides an opportunity for HPC centers with existing Hadoop clusters to move MapReduce jobs over a framework better suited for scientific computing applications. There are similarities between Hama and Hadoop, but for those with high performance computing applications, the most important difference is that with Hama, those all-important bulk synchronous parallel (BSP) parts of the job can communicate, which is something one would not ask MapReduce to do.

There are a few noteworthy sites and projects that leverage Apache Hama for high performance computing purposes, with users that include General Dynamics Mission Systems (details about their porting process here) and at Samsung, where the project’s founder is embedded in research and development. As development continues, one might expect to see more Hama for HPC, although there are still a few limitations that we will get to in a moment.

Hama’s creator, Edward Yoon, saw value in the ability for communication on BSP nodes early on. He joined the Korean electronics giant at about the same time the code went into Apache live preview state and still serves as CEO of of DataSayer, which is trying to commercialize some key work around Hama by adding MPI capabilities based on the core bulk synchronous parallel model that sets Hama apart. He has contributed a great deal of code to both the MRQL query processing system that sits on top of Hadoop and Hama and was also active in building out Apache BigTop. He worked with Hadoop and HBase in their infancy, developing the distributed computing system called Nebula for large-scale data analysis at NHN, then spent two years as a mentor at Google, further refining the Apache projects he helped spin out.

Much of Yoon’s work has fed into a recent upsurge in interest around Hama for HPC applications and while it is limited by nature of the relatively few HPC sites that have dedicated Hadoop clusters, there are some promising benchmarks. For instance, a research team in Beijing compared HAMA versus Hadoop on a modest four-node cluster using a Monte Carlo Pi algorithm to test performance.

Before we get to their findings, it is useful to highlight where Hama sits in relation to Hadoop. As shown on the right, many of the standard elements of Hadoop sit beneath Hama—it’s the communication layer and approach that are unique. The technical explanation, as given by Yoon, is that Hama delivers a parallel matrix computational package, which provides an library of matrix operations for the large-scale processing development environment and Map/Reduce framework for the large-scale Numerical Analysis and Data Mining, which need the intensive computation power of matrix inversion (linear regression, PCA, SVM, for example).

“Currently, several shared-memory based parallel matrix solutions can provide a scalable and high performance matrix operations, but matrix resources can not be scalable in the term of complexity. And, Hadoop HDFS Files and Map/Reduce can only used by 1D blocked algorithm. Hama approach proposes the use of 3-dimensional row and column (qualifier), Time space and multi-dimensional columnfamilies of HBase, which is able to store large sparse and various type of matrices (e.g. Triangular Matrix, 3D Matrix, and etc.) and utilize the 2D blocked algorithm. its auto-partitioned sparsity sub-structure will be efficiently managed and serviced by Hbase. Row and Column operations can be done in linear-time, where several algorithms, such as structured Gaussian elimination or iterative methods, run in O(the number of non-zero elements in the matrix / number of mappers) time on Hadoop Map/Reduce.”

The benchmark results from the comparison between Hadoop and Hama for the representative algorithm highlighted a few interesting points. First, the performance of Hama versus Hadoop was hands-down in favor of Hama, but there was a caveat—the more iterations meant far weaker performance. The BSP part of the process is where the logjam tends to happen, but according to this particular study, if the iterations are kept under a certain number (cannot be identified since it depends on an experiment’s data and requirements) the performance benefits are quite impressive.The Hama teams have built out a more developed approach to Hama over Infiniband as well bolstering Hama’s use with both Mesos and YARN and according to the roadmap that has been published, are seeking to address the BSP overhead.
